Double beam cutting machine

Double beam asynchronous cutting system, intelligent avoidance, anti-collision machine, single machine occupies less space, double machine has higher efficiency. It adopts advanced and mature rolling table design, the platform width can be customized, the theoretical cutting length is unlimited, and

Model : DN5-2H
Application : Garment|Household|Shoe bag|Automotive|Packaging|Composites
Category : Digital Cutter
SALES : 18665806168 Mr Yang

Product introduction

Functional features

High-speed motion control system

It adopts a high-end six-axis high-speed motion control system with independent intellectual property rights. The system upgrade and maintenance are not controlled by a third party. It is convenient for later maintenance, with high reliability and low cost. Because the control is in hand, special programs can be easily customized for the user personalized needs and remote upgrades can be performed.

Independent motion control card

The controller has been upgraded from the computer motherboard plug-in card era to the high-performance integrated circuit controller era. It can be connected to any ordinary computer (including laptops), completely eliminating the problem of cutting equipment paralysis caused by computer link failure.

Modular structure design

It adopts the internationally advanced replaceable tool head design concept. The tool head is not fixed and welded integrated. It can be easily replaced and equipped with tool heads with different functions according to actual work needs and business scope expansion. It solves the problem that fixed integrated tool heads cannot be upgraded due to new demands. Compared with pneumatic heads, it also solves the problem that pneumatic pressure cannot be kept constant due to fluctuations in temperature and time.

Any combination of functions

In addition to the traditional cutting tools such as vibration cutter, drag cutter, half cutter and drawing pen, tool-type milling tools can also be selected. Depending on the different needs of different materials, functions such as writing and drawing lines, dotted line cutting, half-cut cutting, and full-cut cutting can be realized. Various flexible materials such as Chevron board, KT board, adhesive board, corrugated paper, gray board, honeycomb board, white cardboard, kraft paper, red cardboard, EPE foam, etc. can be cut.

Convenient network transmission

It uses a network interface with fast transmission speed and long distance. One computer can control multiple devices (the computer can be replaced at will). Compared with the old serial port, parallel port, and PCI interface, it is more stable and convenient.

Powerful and efficient suction

The energy-efficient partitioned vacuum adsorption system ensures that the material can be optimally fixed. The machine table is made of an integrated ground aluminum honeycomb panel, which has good air permeability, high precision, durability and is not easy to deform.

Work safety

Equipped with a safety device (the machine will automatically stop if a person's hand enters the infrared range).

High efficiency and labor saving

Fast speed 1500mm/s.

Flexible tool combination

The flexible tool system is compatible with all DN5 series products.

TOOLS

Production efficiency

It can cut paper, leather, cloth, PVC, carbon fiber, cotton and other non-metallic flexible materials. The unparalleled production efficiency comes from the application of intelligent control technology, powerful system components and advanced tooling. Perfect coordination, so the system components guarantee the optimization of the production process.

Intelligence brings high performance

High-performance cutter controller with high-performance servo motor, intelligent, detail-optimized cutting technology and precise, maintenance-free drive. With excellent cutting performance, low operating costs and easy integration into production processes.

Efficient material fixing

The energy-efficient and adjustable vacuum system ensures that the material is optimally fixed. You no longer have to worry about the material moving during processing. In addition to ensuring the cutting quality, you will undoubtedly enjoy lower energy consumption.

Front large electric box

Scientific and concise wiring system and chassis circuit design, stable and safe; equipped with all tool interfaces, supporting the subsequent addition and upgrade of all tools; easier installation, repair and maintenance.

Safety protection system

The precise shooting system and the emergency stop switch to prevent misoperation ensure production safety in all aspects.

Double rod cylinder

It adopts double-rod cylinder, with uniform and high pressure, stable material pulling for a long time and not easy to be damaged.

DNCUT Editing software

Powerful editing CAD design software, the perfect combination of Montana, CDR, AI, ONYX, CALDERA, Printfactory software; Database support bar code read die cutter line, improve the work efficiency, reduce the error rate.

Cutting videos

Technical parameters

Model

DN5-2H

Working area(L*W)

2500*1600mm | 2500*1800mm | 3000*2000mm | 5000*1600mm

Overall-dimensions(L*W)

3600*2300mm | 3600*2500mm | 4100*2700mm | 6100*2300mm

Special size

Can be customized

Tools

EOT,UCT,KCT,UDT,POT,PRT,CTT1,VCT

Safety device

Physical anticollision structure + infrared induction anti-collision, ensure production safety

Cutting thickness

0.2-60mm(Can be customized)

Cutting materials

Honeycomb cardboard, corrugated paper, insulating board, grey board paper, white cardboard, film, composite materials, leather, cloth, plastic board, pearl cotton, heat preservation, sound insulation cotton, gaskets and other materials.

Cutting speed

≤1200mm/s(according to different cutting materials)

Cutting accuracy

±0.1mm

Repeated accuracy

≦0.05mm

Cutting circular

≧3mm diameter

Positioning way

CCD camera and Laser positioning

Fixed mode

Vacuum adsorption

Transport interface

Ethernet front-end ports

Software format

AI software, AutoCAD, CorelDRAW, and all of the box type design software can output directly, without conversion, and with automatic optimization

Instruction system

HP-GL compatible format

Operation panel

Multilingual LCD touch panel

Transmission system

High precision linear guide, precision gear rack transmission structure, servo motor and drive

Voltage

AC220V 380V ±10%,50HZ;Power 9kw

Pump power

7.5KW(default)

Work environment

Temperature:-10℃~40℃,Humidity:20%~80%RH

Application industry

Clothing, textiles, household, shoes, leather bags, sound insulation, sealing, automotive, aerospace, new energy, etc
